Product Description of Amaxpower VRLA Lead Acid Battery (12V 17Ah)
Amaxpower Sealed lead acid battery 12v 17ah ups battery backup for medical equipment and Electric Powered Toys
Amaxpower China Factory OEM High Good Quality Battery 12v 7ah/9ah/12ah/17ah/24ah Lead Acid Battery Deep Cycle Battery for UPS and Solar Power system Energy Storage Battery.
Valve-regulated Lead Acid solar battery use particular alloy and material technology design to ensure a excellent performance in various environments, especially high and low temp. Bosfa Solar series batteries is optimal for storage and conversion of photovoltaic energy and wind energy.Amaxpower GS series Sealed free maintenance lead acid batteries are designed with AGM technology,high performance plates and electrolyte to gain extra power output for common power backup system applications widely used in the fields of UPS, Security and Emergency lighting system.
GS 2V Series Sealed Free Maintenance VRLA AGM battery, own 8-10years long life, your best partner for solar market and hot area.
Features and Advantages
Specification
| Nominal Voltage | 12V (6 cells) | |
| Nominal Capacity | 17Ah@20 hour-rate | |
| Dimension | Length | 181±2(7.13 inches) |
| Width | 77±2(3.03 inches) | |
| Height | 167±2(6.57 inches) | |
| Total Height | 167±2(6.57 inches) | |
| Weight | Approx. 5.0kg (11.02lbs) | |
| Reference Capacity (25°C/77°F ) | 20 hour rate (0.85A) | 17Ah |
| 10 hour rate (1.56A) | 15.6Ah | |
| 5 hour rate (2.78A) | 13.9Ah | |
| 3 hour rate (3.97A) | 11.9Ah | |
| 1 hour rate (10.2A) | 10.2Ah | |
| Max. Discharge Current (25°C/77°F) | 110A (5S) | |
| Internal Resistance | Full charged at 25℃(77°F): Approx. 20mΩ | |
| Charge (Constant Voltage) (25°C/77°F) |
Cycle Use |
Voltage: 14.4-15.0V Initial Charging Current: Less than 5.1A |
| Float Use | Voltage: 13.6-13.8V | |
| Operating Temperature Range | Discharge | -20~50°C |
| Charge | 0~50°C | |
| Storage | -20~50°C | |
| Nominal Operating Temperature Range | 25°C ±3°C(77±3°F) | |
|
Capacity affected by Temperature (20 hour rate) |
40°C(104°F) | 102% |
| 25°C(77°F) | 100% | |
| 0°C(32°F) | 85% | |
| -15°C(5°F) | 65% | |
| Self-Discharge (25°C/77°F) | After 3 month | 91% |
| After 6 month | 82% | |
| After 12 month | 64% | |
| Container Material | ABS Plastic | |
-Electric Powered Vehicles -Golf Cars and Buggies
-Wheel Chairs -Power Tools
-Electric Powered Toys -Control System
-Medical Equipments -UPS Systems
-Solar and Wind -Emergency Systems
